Description
Tongwei Solar 465 W N-Type TNC 2.0 | TWMNH-48HW Series
MAIN FEATURES
The Tongwei TWMNH-48HW465 solar panel is engineered with high-efficiency N-Type technology and half-cell architecture, which reduce internal losses and enhance overall energy performance. With a power output of 465 W and an efficiency of 23.3%, this module delivers an ideal balance between performance, reliability, and cost per watt, making it perfectly suited for residential and commercial installations.
The bifacial configuration and double tempered glass (2 mm + 2 mm) allow increased solar radiation capture from the rear side, maximizing energy yield in systems with adequate ground reflectance. Its aesthetic design with a black anodized frame ensures seamless visual integration on visible rooftops.
Thanks to its robust construction and IP68 protection rating, this panel is capable of withstanding demanding environments, with certified resistance to salt mist, ammonia, dust, and sand. High mechanical load ratings of up to 5400 Pa (snow) and 2400 Pa (wind) guarantee durability and long-term reliability throughout its service life.
TECHNICAL SPECIFICATIONS
Electrical Data (STC):
- Nominal power (Pmax): 465 W
- Module efficiency: 23.3%
- Voltage at maximum power (Vmp): 30.56 V
- Current at maximum power (Imp): 15.22 A
- Open-circuit voltage (Voc): 36.40 V
- Short-circuit current (Isc): 15.92 A
- Power tolerance: 0 ~ +3
Mechanical Data:
- Cell type: N-Type monocrystalline Half-Cell
- Configuration: 96 cells (48 × 2)
- Dimensions: 1762 × 1134 × 30 mm
- Weight: 23.7 kg
- Glass: Double tempered glass (2 mm + 2 mm)
- Frame: Black anodized aluminum
- Connectors: MC4 or compatible
- Junction box: IP68, 3 diodes
Operating Conditions:
- Operating temperature range: –40 °C to +70 °C
- Maximum system voltage: 1500 V DC
- Maximum series fuse: 30 A
- Temperature coefficient (Pmax): –0.28 %/°C
ADDITIONAL BENEFITS
- Product warranty: 15 years
- Linear performance warranty: 30 years
- Certifications: IEC 61215 / IEC 61730 / IEC 61701 / IEC 62716 / ISO 9001 / ISO 14001 / ISO 45001
- Higher energy yield thanks to bifacial design
- High resilience to corrosive or extreme environments
- Optimized for residential and commercial projects
This TWMNH-48HW465 module from Tongwei Solar combines efficiency, robustness, and modern design, delivering a reliable solution for installations seeking sustained performance and stable energy returns.
