Description
QCells 505W N-type | Series (Q.TRON M-G3R.12+ / BFG)
The Qcells Q.TRON CLASSIC 505 W is a high-efficiency photovoltaic module designed for residential, commercial, and industrial installations, as well as ground-mounted projects. It integrates N-type monocrystalline cells based on Q.ANTUM NEO technology and a 108 half-cell configuration, engineered to enhance energy yield, reduce electrical losses, and ensure stable performance under real operating conditions.
Its construction features 2.0 mm front glass with anti-reflective treatment, 2.0 mm rear glass, and an anodized aluminum frame, providing high mechanical robustness for demanding environments. The module is certified for snow loads up to 5400 Pa and wind loads up to 2400 Pa, making it suitable for projects requiring structural reliability and long-term durability.
In terms of performance, this model achieves a minimum efficiency of 22.7% under STC for the 505 W version. It also incorporates Anti LeTID, Anti PID, and Hot-Spot Protect technologies specified by the manufacturer, focusing on operational safety, production stability, and protection of return on investment in professional installations. Qcells provides a 25-year product warranty and a 30-year performance warranty.
ESPECIFICATIONS
Electrical Data (STC):
- Nominal Power (Pmax): 505 W
- Voltage at Maximum Power (Vmp): 33.94 V
- Current at Maximum Power (Imp): 14.88 A
- Open Circuit Voltage (Voc): 40.24 V
- Short Circuit Current (Isc): 15.92 A
- Module Efficiency: ≥ 22.7 %
- Power Tolerance: +5 W / −0 W
Mechanical Data:
- Cell Type: Monocrystalline Q.ANTUM NEO solar half cells
- Cell Arrangement: 6 × 18
- Dimensions: 1961 mm × 1134 mm × 30 mm
- Weight: 27.0 kg
- Frame: Anodized aluminum
- Junction Box: 53-67 mm × 28 mm × 17 mm, protection class IP68, with bypass diodes
- Connectors: Stäubli MC4-EVO2A; IP68
- Cables: 4 mm² solar cable; (+) ≥ 1400 mm, (−) ≥ 1400 mm
Temperature Coefficients:
- Pmax: −0.28 %/K
- Voc: −0.24 %/K
- Isc: +0.04 %/K
ADDITIONAL BENEFITS
- International Certifications: TÜV Nord; IEC 61215:2016; IEC 61730:2016; compliant with DIN EN 50380
- Extended Warranty: 25-year product warranty and 30-year performance warranty
