ATMOCE Solutions
Official ATMOCE distributor for professionals
At Vico Export Solar Energy, we are official distributors of ATMOCE, a manufacturer specialising in smart solutions for solar power generation, energy storage and energy management. Its ecosystem integrates microinverters, batteries, backup systems, energy management devices and electric vehicle charging solutions, offering modular and scalable solutions for residential, commercial and industrial installations.
ATMOCE Energy Ecosystem
Explore the key solutions within the ATMOCE ecosystem and go directly to each category.
ATMOCE MI Series microinverters optimise solar power generation through independent MPPT tracking at module level, maximising the energy yield of each panel. Available in 1-in-1 and 2-in-1 configurations, they offer high conversion efficiency, individual monitoring and flexibility for residential and commercial solar installations.
ATMOCE
MI Series Microinverters
1-in-1 Solution
- Rated AC power: 400–600 W
- Configuration: 1 PV module per microinverter
- Max. input current: 16 A
- MPPT range: 16–60 V
- Maximum efficiency: 97.4%
- Communication: PLC
- Protection rating: IP67
- Warranty: 25 years
MODELS
ATMOCE
MI Series Microinverters
2-in-1 Solution
- Rated AC power: 800–1,200 W
- Configuration: 2 PV modules per microinverter
- Max. input current: 20 A per input
- MPPT range: 16–60 V
- Maximum efficiency: 98.2%
- Communication: PLC
- Protection rating: IP67
- Warranty: 25 years
MODELS
ATMOCE energy management systems integrate distribution, communication and monitoring solutions to simplify the control of photovoltaic installations. The M-Combiner range enables microinverters to be integrated into the electrical installation, while M-Gateway facilitates system communication and monitoring. These solutions provide efficient, connected energy management, adapting to different residential, commercial and industrial configurations.
ATMOCE
M-Combiner Lite
MC100L
- Configuration: Single-phase
- Maximum PV power: 5 kW
- Battery capacity: 7 kWh
- PV branch circuits: 1
- Maximum PV current: 20 A
- Rated voltage: 220/230/240 V
- Communication: PLC, Wi-Fi, BLE, Ethernet, CAN
- Protection rating: IP65
MODEL
ATMOCE
Single-phase M-Combiner
MC100
- Configuration: Single-phase
- Maximum PV power: 10 kW
- Battery capacity: 21 kWh
- PV branch circuits: 2
- Maximum PV current: 20 A per branch circuit
- Rated voltage: 220/230/240 V
- Communication: PLC, Wi-Fi, BLE, Ethernet, CAN, RS485
- Protection rating: IP65
MODEL
ATMOCE
Three-phase M-Combiner
MC100-T
- Configuration: Three-phase
- Maximum PV power: 30 kW
- Battery capacity: 42 kWh
- PV branch circuits: 2
- Maximum PV current: 20 A per branch circuit
- Rated voltage: 220/380 V or 230/400 V
- Communication: PLC, Wi-Fi, BLE, Ethernet, CAN, RS485
- Protection rating: IP65
MODEL
ATMOCE
M-Combiner PRO
Single-phase and three-phase solution
- Configuration: Single-phase / Three-phase
- Backup switchover time: 0 ms
- Rated voltage: 220–240 V / 380–415 V
- Protection rating: IP65
- Communication: Wi-Fi, BLE, Ethernet, CAN, RS485
- Integrated gateway: MG100
- Integrated relay: MR100-S / MR100-T
- Compatibility: diesel generator and third-party PV systems
MODELS
ATMOCE
M-Gateway
MG100
- Supported microinverters: Up to 90 units
- Configuration: Single-phase / Three-phase
- Communication: PLC, Wi-Fi, BLE, Ethernet, CAN, RS485
- Monitoring: ATMOCE Cloud / ATMOZEN
- Rated frequency: 50/60 Hz
- Power consumption: less than 5 W without USB
- Protection rating: IP30
MODEL
ATMOCE energy storage solutions enable the use of solar energy generated through modular battery systems based on LiFePO₄ (LFP) technology. The M-ELV Battery range offers an extra-low-voltage storage architecture, designed to integrate with the ATMOCE ecosystem and support smart energy management, self-consumption and backup power functions in compatible configurations.
ATMOCE
M-ELV Battery
MS-7K-U
- Nominal capacity: 7 kWh
- Maximum output power: 5 kVA
- Technology: LiFePO₄ (LFP)
- Nominal battery voltage: 25.6 V DC
- AC round-trip efficiency: 90%
- Cycle life: 10,000 cycles
- Configuration: Single-phase / Three-phase
- Protection rating: IP66
MODEL
ATMOCE
M-ELV Battery
MS-8K-U / MS-8K-U PRO
- Nominal capacity: 8 kWh
- Maximum output power: 5 kVA
- Technology: LiFePO₄ (LFP)
- Nominal battery voltage: 25.6 V DC
- AC round-trip efficiency: 90%
- Cycle life: 10,000 / 15,000 cycles (PRO)
- Configuration: Single-phase / Three-phase
- Protection rating: IP66
MODELS
ATMOCE
M-ELV BattBank
MS-16K-U
- Nominal capacity: 16.08 kWh
- Rated output power: 6 / 8 kVA
- Technology: LiFePO₄ (LFP)
- Nominal battery voltage: 51.2 V DC
- AC round-trip efficiency: ≥90%
- Scalable capacity: up to 80.4 kWh
- Configuration: Single-phase / Three-phase
- Protection rating: IP66
MODEL
ATMOCE backup and protection solutions enable the integration of backup power and electrical protection functions into photovoltaic installations. The M-Backup range facilitates power supply management in systems with energy storage, while M-Relay devices provide protection and grid connection functions. Both solutions are available in single-phase and three-phase configurations to suit different installation requirements.
ATMOCE
M-Backup
Single-phase and three-phase solution
- Configuration: Single-phase / Three-phase
- Max. load current: 63 A
- Max. grid current: 80 A
- Rated voltage: 220–240 V / 380–400 V
- Rated frequency: 50/60 Hz
- Communication: CAN, RS485, DI, DO
- Protection rating: IP65
- Operating temperature: -30 to 50 °C
MODELS
ATMOCE
M-Relay
Single-phase and three-phase solution
- Configuration: Single-phase / Three-phase
- Rated current: 40 A
- Max. current: 50 A/phase
- Rated voltage: 220–240 V / 380–400 V
- Rated frequency: 50/60 Hz
- AC surge protection: Type II
- Communication: RS485
- Protection rating: IP20
MODELS
ATMOCE electric mobility solutions enable electric vehicle charging to be integrated into a smart energy ecosystem. The M-EV Charger range offers single-phase and three-phase chargers with power ratings from 7 to 22 kW, scheduled charging, dynamic load balancing and app-based management. Designed for residential and commercial installations, they help maximise the use of solar energy and provide efficient, safe charging.
ATMOCE
M-EV Charger
Electric vehicle charger
- Rated power: 7–22 kW
- Configuration: Single-phase / Three-phase
- Rated current: 16 / 32 A
- Connector: Type 2 cable
- Charging: Scheduled and dynamic
- Communication: Wi-Fi, Ethernet, Bluetooth
- Protocol: OCPP 1.6 JSON
- Protection rating: IP65 / IK10
MODELS
ATMOCE
M-EV Charger Type 2
MEV-7KT2S-S
- Rated power: 7 kW
- Configuration: Single-phase
- Rated current: 32 A
- Connector: Type 2 socket with shutter
- Start modes: Plug & Charge, RFID, App
- Communication: Wi-Fi, 4G, Bluetooth
- Protocol: OCPP 1.6 JSON
- Protection rating: IP54 / IK10
MODEL
The ATMOCE smart monitoring platform connects the various components of the photovoltaic ecosystem to simplify energy monitoring and management. Through the ATMOZEN App and ATMOCE Cloud, users and professionals can access information on solar generation, energy storage, consumption and the operation of compatible devices, with monitoring and control tools tailored to each installation.
ATMOZEN App
ATMOZEN App allows you to monitor and manage your energy system from your mobile phone, making it easy to track solar generation, electricity consumption and energy storage status.
- Monitor energy generation and consumption.
- View energy flows within the system.
- Track the status of compatible batteries.
- Access generation and consumption data.
- Monitor connected devices.
ATMOCE Cloud
ATMOCE Cloud provides a connected platform for monitoring and managing photovoltaic installations, allowing you to access operating data, analyse energy performance and track equipment status.
- Monitor connected photovoltaic installations.
- Track the status of microinverters and devices.
- Access operating data and energy statistics.
- View system performance.
- Remote management functions subject to compatibility and permissions.
Why choose ATMOCE?
ATMOCE combines photovoltaic technology, energy storage and smart management in an ecosystem designed to improve energy utilisation and simplify the integration of different solutions.
Energy system safety
Module-level power conversion architecture, extra-low-voltage storage and protection solutions designed to enhance system safety.
Maximum efficiency
Microinverters with independent module-level MPPT tracking and energy management systems that help maximise the use of solar generation.
Modularity and scalability
Configurable and expandable solutions that allow generation and storage to be adapted to the needs of each installation.
Connected ecosystem
Integration of microinverters, batteries, backup and electric mobility with digital tools for monitoring and energy management.
Looking for ATMOCE solutions for your solar project?
At Vico Export Solar Energy, we supply ATMOCE solutions for solar industry professionals. Contact our sales team to check the availability of microinverters, batteries, energy management systems, backup systems and electric vehicle chargers for your upcoming projects.
