Canadian Solar 715W N-Type TOPCon Bifacial | TOPBiHiKu7 Series (CS7N-TB-AG)
KEY FEATURES
N-Type TOPCon Bifacial Technology: This module uses N-Type TOPCon cells with bifacial gain of up to 80% and superior performance even under high-temperature conditions. Ideal for installations aiming to maximize energy production.
Robust and durable design: Structure with 2.0 mm tempered dual glass, anodized aluminum frame, and IP68 protection rating. Withstands loads up to 5400 Pa (snow) and 2400 Pa (wind).
Excellent real-world performance: Temperature coefficient of just -0.29%/°C, low initial degradation (≤1%), and only 0.4% annual degradation over the following 29 years.
Designed for large-scale projects: Its large format (2384 × 1303 × 33 mm) and high efficiency make it an optimal solution for solar parks, industrial rooftops, and agrivoltaic plants.
TECHNICAL SPECIFICATIONS
Electrical Data (STC):
- Nominal Power (Pmax): 710 W
- Voltage at MPP (Vmp): 40.6 V
- Current at MPP (Imp): 17.63 A
- Open Circuit Voltage (Voc): 48.5 V
- Short Circuit Current (Isc): 18.64 A
- Module Efficiency: 23.0%
- Bifacial Gain: up to 23% additional
Mechanical Data:
- Cell Type: N-Type TOPCon Bifacial
- Cell Configuration: 132 (2 × 66)
- Dimensions: 2384 × 1303 × 33 mm
- Weight: 37.8 kg
- Glass: 2.0 mm tempered (front and rear)
- Frame: Anodized aluminum
- Connectors: T6 / MC4-EVO2 / MC4-EVO2A
- Cables: +360 mm / -200 mm
Operating Conditions:
- Temperature Range: -40°C to +85°C
- Maximum System Voltage: 1500 V (IEC/UL)
- Maximum Series Fuse Rating: 35 A
- Temperature Coefficient (Pmax): -0.29% / °C
ADDITIONAL BENEFITS
- Product Warranty: 12 years
- Linear Performance Warranty: 30 years
- Certifications: IEC 61215 / IEC 61730 / UL 61730 / CE / INMETRO / MCS / FSEC / UKCA / ISO 9001 / ISO 14001 / ISO 45001
- High resistance to salt mist, dust, ammonia, and sand
The CS7N-715TB-AG module from Canadian Solar is an ideal solution for large-scale photovoltaic projects that require maximum power, efficiency, and long-term durability.
