Description
Canadian Solar 710W N-Type TOPCon Bifacial | TOPBiHiKu7 Series (CS7N-TB-AG)
KEY FEATURES
N-Type TOPCon Bifacial Technology: This module uses N-Type TOPCon cells with bifacial gain of up to 80% and superior performance even under high-temperature conditions. Ideal for installations aiming to maximize energy yield.
Robust and durable design: Structure with 2.0 mm dual tempered glass, anodized aluminum frame, and IP68 protection rating. Withstands loads of up to 5400 Pa (snow) and 2400 Pa (wind).
Excellent real-world performance: Temperature coefficient of only -0.29%/°C, low initial degradation (≤1%), and just 0.4% annual degradation over the following 29 years.
Designed for large-scale projects: Its large size (2384 × 1303 × 33 mm) and high efficiency make it an optimal solution for solar parks, industrial rooftops, or agrivoltaic plants.
TECHNICAL SPECIFICATIONS
Electrical Data (STC):
- Nominal power (Pmax): 710 W
- Voltage at MPP (Vmp): 40.4 V
- Current at MPP (Imp): 17.59 A
- Open-circuit voltage (Voc): 48.3 V
- Short-circuit current (Isc): 18.59 A
- Module efficiency: 22.9%
- Bifacial gain: up to 20% additional
Mechanical Data:
- Cell type: N-Type TOPCon Bifacial
- Cell configuration: 132 (2 × 66)
- Dimensions: 2384 × 1303 × 33 mm
- Weight: 37.8 kg
- Glass: 2.0 mm tempered glass (front and rear)
- Frame: anodized aluminum
- Connectors: T6 / MC4-EVO2 / MC4-EVO2A
- Cables: +360 mm / -200 mm
Operating Conditions:
- Temperature range: -40 °C to +85 °C
- Maximum system voltage: 1500 V (IEC/UL)
- Maximum series fuse rating: 35 A
- Temperature coefficient (Pmax): -0.29% / °C
ADDITIONAL BENEFITS
- Product warranty: 12 years
- Linear performance warranty: 30 years
- Certifications: IEC 61215 / IEC 61730 / UL 61730 / CE / INMETRO / MCS / FSEC / UKCA / ISO 9001 / ISO 14001 / ISO 45001
- Superior resistance to salt mist, dust, ammonia, and sand
The CS7N-720TB-AG module by Canadian Solar is an ideal solution for large-scale photovoltaic projects that demand maximum power, efficiency, and long-term durability.
