590w Jinko Solar N-type | Tiger Neo 72HL4-(V) Series
MAIN FEATURES
N-Type Technology with TOPCon: Utilizes N-Type cells with tunnel oxide passivated contact (TOPCon) technology, reducing LID/LeTID degradation and improving performance in low-light conditions.
High Power and Efficiency: With a power output of 590W and an efficiency of 22.84%, this panel maximizes energy generation for high-performance applications.
SMBB Technology: Its multi-busbar design optimizes light capture and current collection, enhancing the module’s power output and reliability.
Resistance to Extreme Conditions: Designed to withstand up to 5400 Pa snow load on the front and 2400 Pa wind load on the back, making it ideal for harsh climates.
Low Power Degradation: With only 1% degradation in the first year and 0.4% annual degradation thereafter, this panel ensures stable performance and a lifespan of up to 30 years.
TECHNICAL SPECIFICATIONS
Electrical Data (STC):
- Power Output: 590W
- Optimal Operating Voltage (Vmp): 43.71V
- Optimal Operating Current (Imp): 13.50A
- Open-Circuit Voltage (Voc): 52.63V
- Short-Circuit Current (Isc): 14.13A
- Module Efficiency: 22.84%
Mechanical Data:
- Cell Type: N-Type Monocrystalline with TOPCon Technology
- Cell Arrangement: 144 (72 x 2)
- Dimensions: 2278 x 1134 x 30 mm
- Weight: 27.0 kg
- Front Glass: 3.2 mm tempered glass with anti-reflective coating
- Frame: Anodized aluminum
- Junction Box: IP68
- Connectors: JK03M / JK03M2 / Others*
Operating Temperature:
- Operating Range: -40°C to +85°C
- Temperature Coefficient (Pmax): -0.29%/°C
ADDITIONAL BENEFITS
International Certifications: Complies with IEC 61215, IEC 61730 and meets ISO quality and environmental safety standards.
Extended Warranty: This module includes a 12-year product warranty and a 30-year linear performance warranty.
In summary, the Tiger Neo JKM590N-72HL4 solar panel by Jinko is a high-efficiency, highly durable solution for commercial and industrial applications, delivering exceptional performance under demanding conditions and long-term reliability.
