Description
AIKO Neostar 3P+60 N-Type ABC 545W solar panel | AIKO-A545-MCE60Dw
The AIKO Neostar 3P+60 545W solar panel, model AIKO-A545-MCE60Dw, features third-generation N-Type ABC cells and achieves an efficiency of 24.6%. Its high power density delivers 545 W in a module measuring less than two metres in length, with dimensions of 1,954 × 1,134 × 30 mm.
The back-contact ABC technology removes metal contacts from the front surface to increase the active light-absorbing area. The module also features partial shading optimisation, high-temperature restriction, microcrack resistance and a Pmax temperature coefficient of −0.26%/°C. Its dual-glass construction and black frame provide a reliable solution for photovoltaic projects requiring high power, efficiency and long-term performance.
Key features
545 W and 24.6% efficiency
High power density in a module measuring less than two metres, allowing better use of the available installation area.
N-Type ABC technology
Back-contact architecture that removes metal contacts from the front surface and increases the active light-absorbing area.
Third-generation ABC technology
Part of AIKO’s third generation of ABC modules, developed to deliver higher power, efficiency and energy yield.
Shading optimisation
Design developed to reduce the impact of partial shading on the module’s power generation.
−0.26%/°C temperature coefficient
Improved power retention when the module’s operating temperature increases.
Dual glass and mechanical resistance
2 mm + 2 mm semi-tempered dual glass and resistance to front-side loads of up to 5,400 Pa.
Technical specifications
Electrical data under STC
| Model | AIKO-A545-MCE60Dw |
|---|---|
| Maximum power (Pmax) | 545 Wp |
| Module efficiency | 24.6% |
| Maximum power voltage (Vmp) | 38.50 V |
| Maximum power current (Imp) | 14.16 A |
| Open-circuit voltage (Voc) | 45.70 V |
| Short-circuit current (Isc) | 14.88 A |
| Power tolerance | 0 / +3% |
| Maximum system voltage | 1,500 V DC |
| Maximum series fuse rating | 30 A |
STC: AM 1.5 spectrum, irradiance of 1,000 W/m² and cell temperature of 25°C.
Electrical data under NOCT
- Maximum power (Pmax): 413 Wp
- Maximum power voltage (Vmp): 36.53 V
- Maximum power current (Imp): 11.32 A
- Open-circuit voltage (Voc): 43.36 V
- Short-circuit current (Isc): 12.02 A
NOCT: AM 1.5 spectrum, irradiance of 800 W/m², ambient temperature of 20°C and wind speed of 1 m/s.
Mechanical data and connections
- Cell type: N-Type ABC
- Number of cells: 120, 6 × 20 configuration
- Dimensions: 1,954 × 1,134 × 30 mm
- Weight: 27.1 kg ±3%
- Glass: coated semi-tempered dual glass, 2.0 + 2.0 mm
- Frame: black anodised aluminium
- Junction box: IP68 with 3 bypass diodes
- Cable cross-section: 4 mm² IEC / 12 AWG UL
- Cable length: ±1,200 mm
- Connector: MC4-EVO2A
- Protection class: Class II
- Fire resistance classification: IEC Class A
Temperature coefficients and mechanical resistance
- Pmax temperature coefficient: −0.26%/°C
- Voc temperature coefficient: −0.22%/°C
- Isc temperature coefficient: +0.05%/°C
- Operating temperature range: −40°C to +70°C
- Maximum front-side static load: 5,400 Pa
- Maximum rear-side static load: 2,400 Pa
- Hail test: 35 mm diameter hailstones at 23 m/s
Warranties and degradation
- Product warranty: 15 years
- Product warranty extendable to 25 years
- Linear performance warranty: 30 years
- Maximum degradation during the first year: 1%
- Minimum guaranteed power at the end of the first year: 99%
- Maximum annual degradation from years 2 to 30: 0.35%
- Minimum guaranteed power at the end of year 30: 88.85%
The product warranty extension and all other coverage are subject to AIKO’s applicable terms and conditions.
Certifications and management systems
- IEC 61215
- IEC 61730
- Directive 2014/35/EU
- ISO 9001:2015
- ISO 14001:2015
- ISO 45001:2018
Packaging and supply format
- Modules per pallet: 37
- Pallets per 40 ft HC container: 24
- Modules per 40 ft HC container: 888
- Total power per container: 483.96 kWp
- Modules per standard 20 ft container: 185
- Approximate net module weight per container: 24,064.8 kg
- Gross pallet weight and pallet dimensions: not specified in the datasheet
545 W AIKO solar panel for professional projects
The AIKO Neostar 3P+60 545W combines third-generation N-Type ABC technology, 24.6% efficiency and an optimised temperature coefficient in a module measuring less than two metres. These characteristics increase the installed power per square metre and can help reduce the number of modules, mounting components, connections and other balance-of-system costs.
At Vico Export Solar Energy, we distribute AIKO solar panels and photovoltaic equipment to installers, engineering companies, distributors and EPC contractors. This product is sold by full container load of 888 modules, with national and international shipping available.
Datasheet and enquiries
View the technical documentation for the AIKO Neostar 3P+60 AIKO-A545-MCE60Dw or request a quotation for a full container load.
